Helical Speed Reducer Cast Iron Housing R Series Flange Mounted AC Motor Foot Mounted High Overload Capacity
Product Introduction
This series supports flexible installation methods: providing two options: foot installation and flange installation. Foot installation is widely used in standard production lines, while flange installation is suitable for space limited installations. Its compact structure saves valuable workshop space and has strong transmission efficiency: the two-stage model can reach up to 96%, the three-stage model can reach up to 94%, and the R/R combination model can reach up to 85%, effectively reducing energy consumption during daily operation.
The R series is widely used in various industries and is an ideal choice to meet various industrial needs. It is suitable for the light industry, food and beverage (beer, dairy products), and chemical industries, where stable, low maintenance transmission is crucial. In addition, it is also suitable for scenarios such as escalators, automated warehousing systems, building materials machinery, steel metallurgy, as well as environmental protection, power plants, mining, papermaking, port/airport logistics, etc. Whether it is small-scale production or heavy-duty operation processes, it can meet the general transmission needs of most industrial fields.
|
Product Name: |
R helical gear motor |
Ratio: |
5~201 |
|
Model No. |
37,47,57,67,77,87,97,107,127,157,167,187 |
Color: |
Customized |
|
In Power: |
0.12-200kw |
Output Torque: |
<65000nm |
|
Shell Material: |
Die-cast cast Iron |
Worm Wheel: |
12-2 |
|
Bearing: |
C&U |
Oil Seal: |
KSK, SKF |
|
Lubricant: |
Mineral Oil, Synthetic Oil |
Packing: |
Wooden Box |
|
Warranty: |
1 Year |
Origin: |
Hangzhou Zhejiang |
Product Details
Jiahuang Transmission's R series helical gear reducer is designed to provide excellent performance, reliability, and efficiency in industrial power transmission applications. The reducer adopts precision machined helical gears and a sturdy structure, which can convert high-speed input into low-speed high torque output while minimizing energy loss to the greatest extent possible. The R series complies with international standards (ISO 9001, CE, SGS) and is an ideal choice for high demand industries such as mining, material handling, metallurgy, and automation.
Main features and technical highlights
· Efficiency up to 96%: Precision ground helical gears can reduce friction and heat generation, ensuring optimal energy utilization and lowering operating costs.
· Power range: 0.12 kW to 160 kW, meeting various industrial needs.
· Torque capacity: Output torque ranges from 1.4 N · m to 23200 N · m, supporting heavy-duty applications.
2. Compact modular design
· Space saving structure: Parallel axis configuration and compact housing minimize footprint, making it ideal for space constrained installations.
· Modular flexibility: Compatible with various motors (such as IEC standard motors, brake motors, frequency converter motors) and other gearbox series (such as K, F, S motors), providing customized solutions.
· Installation options: Foot installation (B3), flange installation (B5/B14), and shaft installation for seamless integration.
3. Durable structure and materials
· Gear material: 20CrMnTi alloy steel, treated with carburizing, quenching, and grinding processes, with a surface hardness of HRC 58-62 and excellent wear resistance.
· Shell: High strength cast iron (HT250) provides excellent heat dissipation, shock absorption, and long life in harsh environments.
· Protection level: IP55 sealed, dustproof and waterproof, ensuring reliability in outdoor and humid conditions.
4. Precision performance
· Low noise and vibration: Optimized gear meshing and precise balancing reduce noise to<68 dB, ensuring smooth operation in noise sensitive facilities.
· Reduction ratio: With a wide range from 3.33:1 to 289.74:1 (expandable to 27000:1 with combined R/R configuration), precise speed control can be achieved.
· Input/output flexibility: Solid or hollow shafts are optional, the motor is directly connected, and compatible with servo/stepper motors.
5. Global compliance and adaptability
· Certification: CE, ISO 9001, SGS, and GOST (applicable to the Russian/Ukrainian market).
· Application diversity: Suitable for conveyors, mixers, crushers, cranes, and processing machinery in industries such as mining, cement, and wastewater treatment.
Why choose Jiahuang Transmission?
· Customization: Provide customized solutions for speed ratio, installation, and motor compatibility (such as IEC flanges, brake motors).
· Quality assurance: rigorously tested (such as noise/vibration analysis, load tolerance) and certified (ISO 9001, CE, SGS).
· Global support: Provide 12 months of warranty and technical services for various industries worldwide.
Application
 |
 |
 |
| Industrial conveying field | Mining machinery field | Construction machinery field |
 |
 |
 |
| Food processing field | Logistics and warehousing field | New energy sector |
 |
 |
 |
| Metallurgical field |
Chemical engineering field |
Agricultural machinery field |
