Location: China
Business Type: Manufacturer, Exporter
Brands: JIAHUANG
Price: Consultation
中心距:Center Distance A | 电机法兰Motor Flange | 输入轴孔直径UA The Hole Diameter of Shaft | ||||||||||||||
PAM IEC | N | M | P | 传动比ITransmission Ratio | ||||||||||||
5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | |||||
NMRV025 | 56B14 | 50 | 65 | 80 | 9 | 9 | 9 | 9 | 9 | / | 9 | 9 | 9 | 9 | / | / |
NMRV030 | 63B5 | 95 | 115 | 140 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | / | / | / |
63B14 | 60 | 75 | 90 | |||||||||||||
56B5 | 80 | 100 | 120 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | / | |
56B14 | 50 | 65 | 80 | |||||||||||||
NMRV040 | 71B5 | 110 | 130 | 160 | 14 | 14 | 14 | 14 | 14 | 14 | 14 | 14 | / | / | / | / |
71B14 | 70 | 85 | 105 | |||||||||||||
63B5 | 95 | 115 | 140 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | |
63B14 | 60 | 75 | 90 | |||||||||||||
56B5 | 80 | 100 | 120 | / | / | / | / | / | / | / | / | 9 | 9 | 9 | 9 | |
NMRV063 | 90B5 | 130 | 165 | 200 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | / | / | / | / | / |
90B14 | 95 | 115 | 140 | |||||||||||||
80B5 | 130 | 165 | 200 | 19 | 19 | 19 | 19 | 19 | 19 | 19 | 19 | 19 | 19 | / | / | |
80B14 | 80 | 100 | 120 | |||||||||||||
71B5 | 110 | 130 | 160 | / | / | / | / | / | / | / | 14 | 14 | 14 | 14 | 14 | |
71B14 | 70 | 85 | 105 | |||||||||||||
NMRV075 | 100/11285 | 180 | 215 | 250 | / | 28 | 28 | 28 | / | / | / | / | / | / | / | / |
100/112B14 | 110 | 130 | 160 | |||||||||||||
90B5 | 130 | 165 | 200 | / | 24 | 24 | 24 | 24 | 24 | 24 | 24 | / | / | / | / | |
90B14 | 95 | 115 | 140 | |||||||||||||
80B5 | 130 | 165 | 200 | / | / | / | / | 19 | 19 | 19 | 19 | 19 | 19 | 19 | 19 | |
80B14 | 80 | 100 | 120 | |||||||||||||
71B5 | 110 | 130 | 160 | / | / | / | / | / | / | / | 14 | 14 | 14 | 14 | 14 | |
NMRV090 | 100/11285 | 180 | 215 | 250 | / | 28 | 28 | 28 | 28 | 28 | 28 | / | / | / | / | / |
100/112B14 | 110 | 130 | 160 | |||||||||||||
90B5 | 130 | 165 | 200 | / | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | / | / | |
90B14 | 95 | 115 | 140 | |||||||||||||
80B5 | 130 | 165 | 200 | / | / | / | / | 19 | 19 | 19 | 19 | 19 | 19 | 19 | 19 | |
80B14 | 80 | 100 | 120 | |||||||||||||
NMRV110 | 132B5 | 230 | 265 | 300 | / | 38 | 38 | 38 | 38 | / | / | / | / | / | / | / |
132B14 | 130 | 165 | 200 | |||||||||||||
100/11285 | 180 | 215 | 250 | / | 28 | 28 | 28 | 28 | 28 | 28 | 28 | 28 | 28 | / | / | |
90B5 | 130 | 165 | 200 | / | / | / | / | / | 24 | 24 | 24 | 24 | 24 | 24 | 24 | |
90B14 | 95 | 115 | 140 | |||||||||||||
80B5 | 130 | 165 | 200 | / | / | / | / | / | / | / | / | / | / | 19 | 19 | |
NMRV130 | 132B5 | 230 | 265 | 300 | / | 38 | 38 | 38 | 38 | 38 | 38 | 38 | / | / | / | / |
132B14 | 130 | 165 | 200 | |||||||||||||
100/11285 | 180 | 215 | 250 | / | / | / | / | / | 28 | 28 | 28 | 28 | 28 | / | / | |
90B5 | 130 | 165 | 200 | / | / | / | / | / | / | / | / | / | / | 24 | 24 | |
90B14 | 95 | 115 | 140 | |||||||||||||
NMRV150 | 160B5 | 250 | 300 | 350 | / | 42 | 42 | 42 | 42 | 42 | / | / | / | / | / | / |
132B5 | 230 | 265 | 300 | / | / | / | / | 38 | 38 | 38 | 38 | 38 | / | / | / | |
132B14 | 130 | 165 | 200 | |||||||||||||
100/112B5 | 180 | 215 | 250 | / | / | / | / | / | / | / | / | 28 | 28 | 28 | 28 |
Product name:NMRV Method Worm Gear Blue Reducer Co...
NMRV round flange machine-installation precautions...
Advantage performance: 1.Compact structure, light ...
Product Name:Speed Reducer Die Cast Housing Type:S...
Product Name: Name:Adaptor Flange Colour:Many colo...
Hangzhou Jiahuang Transmission Technology Co.,Ltd. is located at the famous city Hangzhou——Jiangdong Industrial Park, which is only 5km away from Hangzhou International Airport, 6km from Hu-Hang-Yong highway, being convenient in terms of transportation. Jiahuang is an enterprise combining R&D and manufacture as a whole, specializing in developing and producing various RV reducer, worm elevator, gear reducer, cycloidal reducer, opener, valve hoist, and UD planetary stepless gear. Taking the lead in getting its own import and export rights in the same line.
Since the company was established, Jiahuang technology has been devoted to the development of high-tech products. As China Wholesale WP Series Reducer Oil Cover Flange Manufacturers, we engage in developing high-tech products that continue to meet the market demand and follow the ideas of "Innovation, speed, and development".Over the years, we have managed to inrovate equipment along with the technology by continuously introducing international advanced processing and testing equipment to enhance core technology and core competitiveness and ensure sustainable development of the enterprise. Now, our products have spread throughout China and been exported far away to the USA, Europe, and Southeast Asia.
Jiahuang exists not only for profit but also for the philosophy of “science and technology change lives" . As Wholesale WP Series Reducer Oil Cover Flange Suppliers.It provides customers with better products and services and contributes to social progress.
A:We will reply you within 1 hours in working day.
A:We have our own factories, and we also have our own international trade department. We produce and sell our own products.
A:We mainly produce RV reducer, WP reducer and its accessories.
A:Our products cover almost the whole equipment manufacturing industry and the applicable fields of machinery manufacturing and processing industry, mainly in construction machinery, mining machinery, agricultural machinery, ships, petroleum machinery, construction, power accessories, electromechanical, hardware tools and other industries.
A:Yes, we have a strong technical team to produce non-standard products according to drawings or samples provided by customers.
A:Yes, we mainly make national standard products. We develop and produce products according to drawings or samples provided by customers.It mainly includes worm wheel, worm, shaft, flange, box and so on.
A:We have a new energy-saving and environmental protection investment casting production line, a large worm and worm production workshop, complete equipment, annual output of up to 300,000 sets.
A:The company has more than 200 employees, including more than 20 professional and technical personnel.
